SF6 Gas Pressure Gauge for Ring Main Unit (Direct Insertion)-7S-SF6-HF165A

SF6 pressure gauge direct insertion type for ring main unit
creative underline.png

Features:

Xizi Energy’s direct insertion SF6 gas pressure gauge is purpose-built for 12kV/24kV SF6 ring main units (RMUs) and gas-insulated switchgear. Featuring a long stainless steel insertion stem, it enables direct mounting into gas chambers for reliable, visual pressure monitoring.
Equipped with a color-coded dial (red for low pressure, green for normal), it provides instant on-site status checks. The mechanical design requires no power, ensuring stable performance in harsh environments (-30°C to +60°C) with high accuracy and IP65 protection. Compliant with IEC standards, it is ideal for utility grids, industrial substations, and data centers seeking early leak detection and safe grid operation.
Get A Quote
creative underline.png

Description:

Key Features

Direct Insertion Design

    • This SF6 pressure gauge features professional direct insertion design for fast field installation.
    • Fully tailored for 12kV and 24kV ring main units and GIS gas insulated equipment.
    • Long stainless steel stem enables direct chamber mounting without extra adapters.
    • High tight sealing structure ensures stable and accurate SF6 pressure reading.
    • Fits standard RMU mounting structure with no equipment modification required.

Color-Coded Dial

    • Clear color-coded dial design helps staff identify gas status at a glance.
    • Green scale marks the normal safe pressure range from 0.2 bar to 1.0 bar.
    • Red warning area indicates low SF6 pressure and leakage risk.
    • No testing tools needed for daily on-site inspection and routine maintenance.
    • Early pressure warning effectively prevents MV switchgear operation risks.

Stainless Steel Construction

    • Made of high-quality 304 and 316 stainless steel for long service life.
    • Excellent anti-corrosion and anti-vibration performance for outdoor substations.
    • Stable working performance in harsh temperature from -30°C to +60°C.
    • Rust-proof and wear-resistant, suitable for long-term outdoor power operation.

Mechanical Reliability

    • Adopts fully mechanical structure, working without external power supply.
    • Zero electronic components, avoiding circuit failure and signal interruption.
    • IP65 protection grade provides reliable dustproof and waterproof performance.
    • Maintains stable pressure monitoring in complex industrial environments.

IEC Compliance

    • Manufactured in strict accordance with IEC 60282 international standards.
    • All technical indicators comply with global medium voltage power specifications.
    • Universal structure compatible with most mainstream MV switchgear brands.
    • Custom OEM and ODM service available for different project demands.

Technical Specifications

Parameter Specification
Measuring Medium Pure SF6 Gas
Measuring Range 0 – 1.0 bar
Reference Temperature 20°C Standard Condition
Accuracy Class ±1.6% Full Scale
Operating Temperature -30°C ~ +60°C
Installation Method Direct insertion for RMU gas chamber
Protection Level IP65 Dust & Water Resistant
Housing Material 304 / 316 Stainless Steel
Industry Standard IEC 60282, GB/T 11023

Application Scenarios

  • SF6 Ring Main Units (RMU) & Inflatable Cabinets: Primary on-site pressure monitoring component for 12kV/24kV gas-insulated switchgear.
  • SF6 Circuit Breakers & GIS: Integrated into high-voltage SF6 equipment for visual pressure checks.
  • Power Maintenance & Safety: Enables quick on-site inspection for utility teams to detect gas leakage early.
  • No-Power Monitoring Scenarios: Ideal for applications requiring only mechanical visual indication without remote alarms.
