The schneider medium voltage switchgear complete set 7s-sm6-kgg-s1 is a medium-voltage air-insulated switchgear designed around the core principles of “safety, flexibility, and reliability.”
Its modular design and mandatory interlocking mechanisms are defining features, making it widely adopted in fixed distribution applications demanding high levels of safety and scalability.
• Operating Module: Includes closing/opening buttons, status knob, and operational indicator;
• Monitoring Module: Equipped with voltage/current meters and status display screen for real-time power parameter monitoring;
• Core Components: Integrated circuit breaker (e.g., Schneider MVnex series), isolating switch, and protection device,
supporting power distribution and protection functions.
• Intelligent: Supports digital monitoring and remote communication, meeting smart grid operation and maintenance requirements;
• High Reliability: Incorporates industrial-grade insulation design, with mechanical and electrical lifespans meeting medium-voltage equipment standards;
• Safety Interlocks: Features cabinet door-switch operation interlocks and live-voltage indicators to reduce misoperation risks.
• Distribution Branching: Enables multi-circuit distribution of 6kV power;
• Fault Protection: Rapidly interrupts short-circuit and overload currents to safeguard the grid and connected loads;
• Status Management: Provides real-time feedback on equipment operational status to support maintenance and operational decisions.
| Parameter Category | Specifications of Schneider’s Similar 6kV Switchgear |
|---|---|
| Rated Voltage | 6kV |
| Rated Current | 630A~1250A |
| Short-Circuit Breaking Current | 31.5kA (at rated voltage) |
| Protection Rating | IP3X (cabinet body) |
| Mechanical Life | ≥15,000 switching cycles (opening/closing) |
• Industrial Sector: Provides branch power supply and protection for high-voltage motors and transformers in factories and mines;
• Distribution Systems: Used for 6kV line distribution in substations and distribution rooms, supporting regional power dispatch;
• Critical Facilities: Adapts to medium-voltage distribution in data centers and rail transit systems, ensuring highly reliable power supply.
We offer comprehensive OEM and ODM services tailored to your specific requirements. Should you require customized products, our professional team will provide full support to meet your needs.
