1. Maximize Energy Efficiency: ≥98% overall efficiency minimizes power loss, reducing your project’s levelized cost of energy (LCOE) and improving ROI.
2. Robust Grid Compatibility: Supports ±45% voltage ride-through (LVRT/HVRT) and reactive power regulation, fully complying with global grid codes (GB/IEC/CE) for seamless grid integration.
3. Low O&M Cost: Built-in remote monitoring and intelligent fault diagnosis reduces on-site maintenance time and labor costs, ideal for long-term wind farm operation.
4. Harsh Environment Adaptability: IP23 protection, forced air cooling, and wide temperature range (-40°C~+50°C) ensure stable performance in cold plateaus, coastal areas, and high-altitude regions.
5. Flexible Customization: Available in 3.XMW–12.0MW power ratings with customizable dimensions, perfectly matching different wind turbine models and project requirements.
| Category | Specification |
| Power Range | 3.XMW – 12.0MW |
| DC Working Voltage | 855V–1045V / 1026V–1254V (model-dependent) |
| Grid Frequency | 47.5Hz–52.5Hz / 57Hz–63Hz |
| Overall Efficiency | ≥98% |
| Grid Voltage Ride-Through | ±45% |
| Protection Class | IP23 |
| Cooling Method | Forced Air Cooling |
| Operating Temperature | -40°C ~ +50°C (derated above 45°C) |
| Altitude | Standard: ≤3000m; High-Altitude: 3000m–5000m |
| Noise Level | <62dB |
| Dimensions (W×H×D) | Customizable (2000×2000×600mm ~ 4200×2200×700mm) |
