The whole cabinet outline size, mounting holes, busbar interfaces and five-proof interlock system adopt unified industry standards. This SM6 Compatible Medium Voltage Switchgear requires no civil construction transformation during installation, greatly shortening power cut construction time when used as Schneider SM6 replacement switchgear.
All production and testing procedures follow IEC 62271 switchgear specifications. The sealed gas tank structure of this indoor SF6 switchgear effectively prevents moisture and dust intrusion, guaranteeing long-term insulation stability under indoor operation environments.
As classic indoor medium voltage switchgear, the modular combination structure saves indoor substation space. Users can freely collocate incoming, outgoing, metering and protection units according to grid layout needs, convenient for later system expansion.
Universal spare parts matching design simplifies daily inspection and component replacement. For power grid operators and factories running long-term SM6 systems, our equipment drastically reduces overall operation expenses.
We provide professional OEM medium voltage switchgear customization services. Clients can adjust electrical parameters, internal layouts, nameplates and technical documents to meet bidding standards and regional power grid requirements worldwide.
Public power grids are the largest application scene for our ring main unit for power distribution. Urban & rural distribution substations, distribution automation stations and feeder switching rooms all adopt this IEC 62271 medium voltage switchgear for continuous, safe municipal power supply.
Manufacturing workshops, chemical factories, mining and oil & gas facilities need uninterrupted power supply to avoid production losses. Our SF6 insulated switchgear adapts to complex on-site environments, ideal heavy-duty indoor medium voltage switchgear for industrial power distribution systems.
Solar power stations, wind farms and battery energy storage stations need compact, reliable ring main unit switchgear for grid connection. Our SM6 Compatible Medium Voltage Switchgear supports bidirectional current transmission and fast fault cutting, perfectly fitting new energy grid-connected technical demands.
Airports, hospitals, data centers, shopping malls and rail transit hubs all deploy this indoor SF6 switchgear to guarantee power safety for critical public loads.
| Item | Technical Parameter |
|---|---|
| Full Name | SM6 Compatible Medium Voltage Switchgear |
| Executive Standard | IEC 62271 medium voltage switchgear |
| Rated Voltage | 12kV |
| Frequency | 50Hz / 60Hz |
| Rated Current | Up to 630A (Customizable) |
| Short-Time Withstand Current | 20kA / 25kA |
| Insulation Mode | SF6 insulated switchgear |
| Installation Way | Indoor |
| Protection Class | IP4X |
| Operating Mechanism | Manual / Motorized Optional |
| Service Form | Standard supply + OEM medium voltage switchgear |
Note: All technical indexes can be adjusted according to project drawings; consult our engineering team for tailored solutions.
Multiple combinations are supported: incoming feeder cabinet, outgoing feeder cabinet, transformer protection cabinet, metering cabinet, bus section cabinet and complete ring main unit switchgear layout, adapting to all mainstream power distribution topological structures.
As a professional SM6 compatible switchgear supplier, we keep full stock of matching accessories: operating mechanisms, SF6 density gauges, interlocking components, auxiliary switches and busbar fittings, to support long-term equipment maintenance after Schneider SM6 replacement switchgear installation.
All customized OEM medium voltage switchgear strictly abide by IEC 62271 switchgear norms.
A: No. Xizi Energy is an independent medium voltage switchgear manufacturer. This SM6 Compatible Medium Voltage Switchgear is independently designed and manufactured, only used as Schneider SM6 replacement switchgear from technical dimension perspective, without any authorization, cooperation or affiliation with Schneider Electric.
A: Yes. Unified dimensional and interface standards realize seamless replacement. Our engineers will check your site conditions and drawings in advance to confirm full compatibility.
A: Sure. As a professional SM6 compatible switchgear supplier, we provide all-around OEM customization for distributors, EPC companies and power equipment vendors worldwide.
A: Widely used for utilities, industrial plants, renewable energy projects, mining, petrochemical and large commercial infrastructure power distribution.
A: All units are manufactured and inspected in accordance with IEC 62271 medium voltage switchgear international standards.
If you need parameter verification, cabinet scheme design or bulk pricing of the 7S-SM6-KGG-S1 Schneider-compatible medium voltage switchgear, our professional medium voltage engineering team provides global one-stop technical support and procurement solutions. Please submit your project voltage, current and functional requirements to obtain a targeted quotation.
Schneider Electric and SM6 are registered trademarks owned by Schneider Electric. Xizi Energy is an independent medium voltage switchgear manufacturer. Our SM6 Compatible Medium Voltage Switchgear is merely designed for technical compatibility with SM6 series systems, not produced, authorized or endorsed by Schneider Electric.
